Mica Band Heaters GM.54
SKU: GM.54
Mica Band Heaters are primarily used to provide efficient and uniform heating to cylindrical surfaces. They are commonly used in:
Plastic Injection Moulding
Extrusion processes
Die Heads
Packaging Equipment
For elements with a diameter above 400mm, we recommend using more heating segments.
SELECTION
Choosing the right band heater for your application is crucial to ensure optimal performance, energy efficiency, and longevity of your heating system.
Here are key factors to consider when selecting a heater band:
Temperature Range: Determine the maximum operating temperatures required for your process.
Watt Density: Assess the power requirements to achieve the desired heating levels efficiently. Higher watt densities are suitable for faster heating and more demanding applications.
For applications requiring heating elements on surfaces with diameters larger than 400 mm, we recommend using multiple segments of heating elements connected together with clamps.
| Isolation Material: | Micanite |
| Diameter: | From 30 mm |
| Width: | 20 to 800 mm |
| Max Watt density: | 4 W/cmm2 |
| Voltages: | 230, 400V or other |
| Operating temperature: | Up to 350°C |
| Sheath material: | Stainless steel AISI430 |
| Heating conductor: | Nickel-Chrome 80/20 |
| Connection cable: | Temp. resistant cable with steel mesh up to 400°C |
| Outside insulation: | optional 10 mm integrated insulation. |
When to select Micanite Insulated Band heater GM.54
When added insulation is required.
AXIAL CONNECTION BOXES:
RADIAL CONNECTION BOXES:
TANGENTIAL CONNECTION BOXES:
